| Brand Name: | GEZHI or OEM |
| Model Number: | GZ-Patch Cord |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
PVC Material Fiber Optic Patch Cord 10 Meter Length LC DX MM 2.0 Diameter For CATV
Fiber Optic Patch Cord Description
FTTH transmission patch cord ,Fiber optic patch cord (also known as fiber optic connector) ,In multimode fiber jumping cable , the diameter of the core is 50μm~65μm ,Roughly equivalent to the thickness of a person's hair.
Fiber Optic Patch Cord Application
This kinds of cable can be used in data center ,transfer the data between data center and terminal box ,and Fiber patch cord products are widely used in fiber-optic communication systems.
Technical Parameter
| products name | LC DX MM 2.0 diameter PVC material 10meter length fiber optic patch cord for CATV |
| mode type | multi mode |
| cable count | dumplex |
| core type | OM4 |
| cable color | Magenta |
| cable diameter | 2.0mm |
| patch cord length | 10 meter ( can be customized according to your request ) |
| out jacket material | LSZH ( can be PVC or LSZH ) |
| insertion loss | ≤ 0.3dB |
| return loss | ≥40 dB |
| wave length | 850/1300nm |
| core type | 50/125um |
| connector color | beige |
| ferrule material | Ceramic |
| operater temperature | -40~ +85℃ |
| cable print | standard print ( can customized ) |
| OEM/ODM | acceptable |
| warranty | 3 years after delivery |
| Delivery time | 2-15 working days ( according to your quantity ) |
|
|
| Brand Name: | GEZHI or OEM |
| Model Number: | GZ-Patch Cord |
| MOQ: | 1pc |
| Price: | Negotiable |
| Packaging Details: | Paper box |
| Payment Terms: | T/T, Western Union |
PVC Material Fiber Optic Patch Cord 10 Meter Length LC DX MM 2.0 Diameter For CATV
Fiber Optic Patch Cord Description
FTTH transmission patch cord ,Fiber optic patch cord (also known as fiber optic connector) ,In multimode fiber jumping cable , the diameter of the core is 50μm~65μm ,Roughly equivalent to the thickness of a person's hair.
Fiber Optic Patch Cord Application
This kinds of cable can be used in data center ,transfer the data between data center and terminal box ,and Fiber patch cord products are widely used in fiber-optic communication systems.
Technical Parameter
| products name | LC DX MM 2.0 diameter PVC material 10meter length fiber optic patch cord for CATV |
| mode type | multi mode |
| cable count | dumplex |
| core type | OM4 |
| cable color | Magenta |
| cable diameter | 2.0mm |
| patch cord length | 10 meter ( can be customized according to your request ) |
| out jacket material | LSZH ( can be PVC or LSZH ) |
| insertion loss | ≤ 0.3dB |
| return loss | ≥40 dB |
| wave length | 850/1300nm |
| core type | 50/125um |
| connector color | beige |
| ferrule material | Ceramic |
| operater temperature | -40~ +85℃ |
| cable print | standard print ( can customized ) |
| OEM/ODM | acceptable |
| warranty | 3 years after delivery |
| Delivery time | 2-15 working days ( according to your quantity ) |
