| Brand Name: | GEZHI or OEM |
| Model Number: | GZ-CWDM MUX |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
CWDM MUX 18 Channels CWDM System 1U Racks SC FC LC APC UPC PC
Product Description
GEZHI 18CH CWDM Mux/Demux FMU Plug-in Module is built a 18CH Mux LGX cassette + 18CH Demux LGX cassette in one 19" 1U Rack-mount. The wavelenght of 18CH CWDM Mux/Demux FMU Plug-in Module is 1310 to 1610nm.
Features
Low Insertion Loss
High Isolation
Low PDL
Compact Design
18 Channels
Mounted in 191 u Racks or ABS box optional
Wide Operating Wavelength:
From 1260nm to 1620nm
Applications
CWDM System
WDM Network
Specifications
| Parameter | 4 Channel | 8 Channel | 18 Channel | ||||
| Mux | Demux | Mux | Demux | Mux | Demux | ||
| Channel Wavelength (nm) | 1270~1610 | ||||||
| Center wavelength Accuracy (nm) | ±0.5 | ||||||
| Channel Spacing (nm) | 20 | ||||||
| Channel Passband (@-0.5dB bandwidth (nm) | >13 | ||||||
| Insertion Loss (dB) | ≤1.6 | ≤2.5 | ≤3.0 | ||||
| Channel Uniformity (dB) | ≤0.6 | ≤1.0 | ≤1.5 | ||||
| Channel Ripple (dB) | 0.3 | ||||||
| Isolation (dB) | Adjacent | N/A | >30 | N/A | >30 | N/A | >30 |
| Non-adjacent | N/A | >40 | N/A | >40 | N/A | >40 | |
| Inertion Loss Temperature Sensitivity (dB/°C) | <0.005 | ||||||
| Wavelength Temperature Shifting (nm/°C) | <0.002 | ||||||
| Polarization Dependent Loss (dB) | <0.1 | ||||||
| Polarization Mode Dispersion | <0.1 | ||||||
| Directivity (dB) | >50 | ||||||
| Return Loss (dB) | >45 | ||||||
| Maximum Power Handling (mW) | 300 | ||||||
| Opterating Temperature (°C) | -5~+75 | ||||||
| Storage Temperature (°C) | -40~85 | ||||||
| Package dimension (mm) | L100 x W80 x H10 or L140xW100xH15 | ||||||
CWDM MUX/DWDM MUX Solution
What we supply
We supply all kinds of compatible optical transceiver modules, including SFP, SFP+, XFP, BIDI,CWDM,DWDM and other special transceiver modules. Our products are compatible with various brands.
FAQ
Q: Do you sell second-hand products?
A: No.All our products are brand new,we never use secont-hand components.
Q: Do your products come with warranty?
A: Yes,We provide 3 years warranty for all our products from the date of shipment.
Q: How to place an order?
A:1> Order details confirmed,please tell us the model and quantity you need.
2> Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
3> Confirm and ship the goods, then tracking number will be sent to you promptly.
4> We will help to track your goods until you receive them safely.
|
|
