48F MPO(Female) - MPO(Female) 3.0mm LSZH Fiber Optic Patch Cable / Trunk Cable

Name: 48F MPO(Female) - MPO(Female) 3.0mm LSZH Fiber Optic Patch Cable / Trunk Cable
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 48F MPO(Female) - MPO(Female) 3.0mm Trunk Cable
Price: Negotiable USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	48F MPO(Female) - MPO(Female) 3.0mm Trunk Cable
MOQ:	1pc
Price:	Negotiable
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Product Name:

48F MPO(Female) - MPO(Female) 3.0mm Trunk Cable

Connector:

MPO(Female) To MPO(Female)

Fiber Cores:

48F

Certification:

Telcordia GR-1435-CORE Compliant

Application:

FTTX+LAN,Testing Equipment,Telecommunication Networks,Etc

Durability:

<0.3dBtypical Change, 200 Matings

Interchangeability:

≤0.2dB

Packaging Details:

Paper box

Supply Ability:

5000pcs per month

Highlight:

48F Fiber Optic Patch Cable

Product Description

48F MPO(Female) - MPO(Female) 3.0mm LSZH Fiber Optic Patch Cable / Trunk Cable

Product Description

The merits of MTP/MPO Patch cable/trunk cable generally include:

High quality—MTP/MPO Patch cable/trunk cables are factory pre-terminated, tested and packaged along with the test reports. These reports serve as long-term documentation and quality control.

Decreasing cable volume—MTP/MPO Patch cable/trunk cables have very small diameters, which decrease the cable volume and improve the air-conditioning conditions in data centers.

Time saving—With the special plug and play design, MTP/MPO Patch cable/trunk cables can be incorporated and immediately plugged in. It greatly helps reduce the installation time.

Specification

MPO Patch cable/trunk cable ’s Specification:

Spec items.	Single mode (APC 8-degree polished)	Multimode (PC Flat polish)
Insertion loss (MPO) (IEC 61300-3-34)	Standard loss:≤0.75dB(max), ≤0.35dB(Typical) Super Low loss:≤0.35dB(max), ≤0.20dB(Typical)	Standard loss:≤0.6dB(max), ≤0.35(Typical) Super Low loss:≤0.35dB(max) , ≤0.20dB(Typical)
Return loss(MPO)	≥60dB(8degree polishing)	≥25dB
Durability	<0.3dBtypical change, 200 matings
Interchangeability	≤0.2dB
Tensile strength	>70N
Operating Temperature	-40 to + 85°C

Cable Parameters-24-144F Microfiber cable

Fiber number	Flat 24	36 & 48 &72	72	96	144
Subunit diameter (mm)	2.9±0.1	2.9±0.1	2.9±0.1	2.9±0.1	2.9±0.1
Cable diameter(mm)	(4.2±0.3)x(7.6±0.4)	9.0±0.3	11.2±0.3	13.5±0.3	17.5±0.3
Cable weight(kg/km)	(LSZH 52)/ (PVC 44)	(LSZH 93) /(PVC 86)	(LSZH106)/ (PVC 96)	(LSZH146)/ (PVC 135)	(LSZH260)/ (PVC 224)
Max.loading(IEC794-1) Installation/Operation	200/80	1000N/300N
Temperature rating Operation&Storage	-20°C ~70°C

MPO products’ Details& Standard:

Connector

Reference

Housing Details

MPO Single Mode

IEC 61754-7

SM APC: Green connectors+black boot (Standard Loss MPO)

SM APC: Yellow connectors+black boot (Super low loss MPO)

MPO Multimode

IEC 61754-7

OM1&OM2 PC: Beige connectors+black boot (Standard Loss MPO)

OM3&OM4 PC: Aqua connectors+black boot (Standard&Super low loss MPO)

OM3&OM4 PC: Heather Violet connectors+black boot (Standard loss MPO)

Cable Drawing

Length Tolerance

Overall Length(L)(m)	length of tolerance(cm)
0<L<1	+5/-0
1<L<10	+10/-0
10<L<40	+15/-0
40<L	+0.5% x L/-0

Pre-terminated MPO Technology-Polarity
