Patch Cable Series
Created with Pixso. SC APC Singlemode Simplex Fiber Optic Armord Patchcord

SC APC Singlemode Simplex Fiber Optic Armord Patchcord

Brand Name: GEZHI or OEM
Model Number: G-FAP200x
MOQ: 1pc
Price: Negotiable
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Connector Type:
SC APC
Fiber Length:
16m Or Customized
Wavelength:
1310,1550nm Or Customzied
Cable Jacket:
LSZH
Fiber Type:
G657A1
Application:
CATV System
Packaging Details:
Paper box
Supply Ability:
100000Channel per month
Highlight:

Simplex Fiber Optic Patchcord

,

SC APC Fiber Optic Patchcord

,

Singlemode Fiber Optic Patchcord

Product Description



Product Overview

SC APC Singlemode Simplex Fiber Optic Armord Patchcord

Armord Patch Cord

Gezhi Armored patchcords can be laid in all kinds of harsh environments. It has stainless steel tube to protect optical fibers and provides better security for the whole system.We can offer various fiber core sized terminated with SMA905, FC, ST or other type connectors.

Applications

*CATV

*LAN & WAN

*National defense

*Telecommunication networks

*FTTX, FTTH (Fiber to the Home)



Specifications

Mode
SM
Polishing
UPC
APC
Insertion Loss
≤0.3dB
≤0.3dB
Return Loss
≥50dB
≥60dB
Interchangeability
≤0.2dB
Salt Spray
≤0.2dB
Repeatability
≤0.1dB (1,000 times)
High Temperature
≤0.2dB (+85°C 168 hours)
Low Temperature
≤0.2dB (-40°C 168 hours)
Temperature Cycle
≤0.2dB (-40°C~85 °C 21 cycles 168 hours)
Humidity
≤0.2dB (95% 75°C 168 hours)
Durability
≥1,000 matings
Vibration
≤0.1dB (10-55Hz 1.5mm)
Falling
≤0.2dB (1.5m high, 8 times)
Tensile Strength
Long Term
100N
Short Term
200N
Crush Resistance
Long Term
3,000N
Short Term
5,000N
Bending Radius
Dynamic
20D
Static
10D
Operating Temp.
-40°C~+85°C





Other Connectors

SC APC Singlemode Simplex Fiber Optic Armord Patchcord 0



High Quality & Stability Material

SC APC Singlemode Simplex Fiber Optic Armord Patchcord 1 SC APC Singlemode Simplex Fiber Optic Armord Patchcord 2 SC APC Singlemode Simplex Fiber Optic Armord Patchcord 3


FAQ
Q1:Can I have a sample order? What is your MOQ of armord patch cord?
A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms of armord patch cord?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time of armord patch cord?
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
