| Brand Name: | GEZHI or OEM |
| Model Number: | 8 Core OM3 MM Patch Cord |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
2M Fiber Optic MPO 8 Core OM3 MM Patch Cord Fanout LSZH 1310nm Test Wavelength
Description
MPO Breakout cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles.
Features
1.8 core fiber
2. Small volume, easy management
3. Insertion Loss: Low IL & Standard IL available
4. emerging 40 and 100GBPS protocols
5. Conform to EIA-TIA, and Telcordia performance requirements
Specifications
| Type | Single Mode | Single Mode | Multi Mode | |||
|
(APC Polish)
|
(UPC Polish) | (PC Polish) | ||||
| Fiber Count | 8,12,24 | 8,12,24 | 8,12,24 | |||
| Fiber Type | G652D,G657A1 |
G652D,G657A1
|
OM1,OM2,OM3 | |||
|
Maximum Insertion Loss
|
Elite |
Standard
|
Elite |
Standard
|
Elite |
Standard
|
| Low Loss | Low Loss | Low Loss | ||||
| ≤0.35 dB | ≤0.75dB |
≤0.35 dB
|
≤0.75dB | ≤0.35 dB |
≤0.60dB
|
|
| Return Loss | ≥60 dB | ≥60 dB |
NA
|
|||
| Durability | ≥500 times | ≥500 times | ≥500 times | |||
| Operating Temperature |
-40℃ ~ +80℃
|
-40℃ ~ +80℃
|
-40℃ ~ +80℃
|
|||
| Test Wavelength | 1310nm | 1310nm |
1310nm
|
|||
|
|
