OLP Module Optical Line Protection System High Speed Fiber Switch

Name: OLP Module Optical Line Protection System High Speed Fiber Switch
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: Olp Module
Price: Negotiable USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	Olp Module
MOQ:	1pc
Price:	Negotiable
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Product Name:

OLP Optical Line Protection Module

Switch Speed:

<30ms

Operating Temperature:

-10 To +60℃

Operating Wavelength:

1310±50nm/1550±50nm

Working Mode:

Automatic & Manual

Application:

Monitoring System

Packaging Details:

Paper box

Supply Ability:

100000Channel per month

Highlight:

OLP Module Fiber Switch

High Speed Fiber Switch

Product Description

Description of Optical Line Protection

OLP Module Optical Line Protection System High Speed Fiber Switch

Optical Line Protection

OLP-Optical Line Protection is a device that is used in the protection of network transmission line, it can realize optical power monitoring and automatic switching. In optical communication network, OLP constantly monitors optical power of working optical fiber and standby optical fiber.

Features of Optical Line Protection

◆Automatic switching of primary and secondary routes

◆Manual and automatic switching modes

◆High Stability, High Reliability

◆Manual,automatic working mode settings

Technical Parameter

Parameters	Unit	OLP-1:1	OLP-1+1	OLP-1-1
Wavelength Range	nm	1260 ~ 1650
Test Wavelength	nm	1310 / 1550
Insertion Loss	dB	TX<1.2,RX<1.2	TX<4,RX<1.2	<1.2
Return Loss	dB	SM ≥ 45
Crosstalk	dB	SM ≥ 50
PDL	dB	≤ 0.20
WDL	dB	≤ 0.30
PD dark current	nA	＜1
PD responsivity	mA/W	24 ~ 40
PD report accuracy	dB	±0.5 (at -50 to 23 dBm)
Operating voltage	V	4.5 ~ 5.5
Operating current	mA	80 ~ 120
Operating Temperature	℃	-5 ~ +60
Storage Temperature	℃	-30 ~ +80
Dimension	mm	120×80×18

OLP Module Working Theory

1:1

OLP Module Optical Line Protection System High Speed Fiber Switch 0

1＋1

OLP Module Optical Line Protection System High Speed Fiber Switch 1

1-1

OLP Module Optical Line Protection System High Speed Fiber Switch 2

FAQ

Q1:Can I have a sample order? What is your MOQ of Optical Line System Module?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available.  Also Mixed samples are acceptable.

Q2: What's the Lead time?

A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.

Q3: What are the payment terms?

A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.

Q4: What is your warranty time?

A4: 3 years' warranty.

Q5: Could I use our own logo, label and package?

A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
