| Brand Name: | GEZHI or OEM |
| Model Number: | Single mode Optical Fiber Pigtail |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
Manufacture Telecommunication Equipment Single mode Optical Fiber Pigtail
Product Overview
Fiber Optic pigtail has connector at one end, the other end is fiber optic cable which be cut off.
Then it connect by splice with other cable core. It is widely used in fiber optic terminal box, ODF
rack , cabinet to connect with fiber optic media converter/transceivers(use coupler,patch cord too)
Application
|
Features
|
1. Polish Data
| Item | PC Polishing | APC Polishing | ||
| Ferrule Diameter(mm) | 2.5 | 1.25 | 2.5 | 1.25 |
| Radius of Cury(mm) | 10 ~25 | 7~25 | 5~15 | |
| Fiber Height(nm) | -100~50 | ±50 | ||
| Apex Offset(um) | ±50 | ±50 | ||
2.Technical Data
| NO. | Item | Unit | Single Mode | Multi-Mode | ||
| 1 | Insertion Loss | dB | ≤0.2 | ≤0.3 | ≤0.3 | |
| 2 | Return Loss | dB | ≥50/UPC | ≥45/PC | ≥65/APC | ≥35/PC |
| 3 | Repeatability | dB | 0.1 | |||
| 4 | Working Times | Times | ≥1000 | |||
| 5 | Operating Temperature | °C | -40-85 | |||
| 6 | Optical Cable Diameter | mm | Φ0.9 | Φ2.0 | Φ3.0 | |
Product image
|
|
