Patch Cable Series
Created with Pixso. Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable

Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable

Brand Name: GEZHI or OEM
Model Number: Breakout Fiber Cable
MOQ: 1pc
Price: Negotiable
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Warranty Time:
3 Years
Connector Type:
LC,SC,FC, ST, MTRJ,MTP,MPO Etc
Surface Polishing:
PC,APC,UPC
Length:
Customised
Cable Diameter:
0.9mm/ 2.0mm/ 3.0mm
Cable Type:
Simplex,Duplex
Packaging Details:
Paper box
Supply Ability:
100000Channel per month
Highlight:

LC UPC Duplex Breakout Cable

,

MPO Female Breakout Cable

,

Single Mode Breakout Cable

Product Description

Product Overview



Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable



MPO OS2 Breakout Cables



GEZHI Photonics manufactures data center grade fiber optic MPO patch cords. The MPO connector uses a spring loaded sliding mechanism allowing the fiber patch cord to latch onto adapters providing a secure and reliable connection for network cabling in enterprise data centers, backbone, colocation facilities, server farms, cloud storage networks, and telecommunication rooms. Each assembly is 100% factory tested to meet IEC 61753-1 standard.





Applications

High-density Data Center
Storage area networking
Optical System Access network
40GbE & 100GbE SR optics direct connection







Test Environment

Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 0    Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 1   Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 2  Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 3



    NO-dust workshop                High Temp. Ageing & High-Low               100% Testing Before              Optical Spectrum Analysis

                                                            Temperature cycling                            Shipment





ordering information



Performance Level Standard Elite
Connector Mode Endface IL(max) (dB) RL(min) (dB) IL(max) (dB) RL(min) (dB)
MPO SM 12F 0.70 60 0.35 60
24F 0.75 60 0.35 60
LC/SC/FC/ST SM APC 0.30 60 0.10 60
UPC 0.20 50 0.10 50












Product packaging

Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 4  Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 5  Best Price MPO Female to LC UPC Duplex OS2 Single Mode Breakout Cable 6

           Finished Item              Inner Package                     Carton
