High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord

Brand Name: GEZHI or OEM
Model Number: SMA Fiber Cable
MOQ: 1pc
Price: Negotiable
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Warranty Time:
3 Years
Name:
SMA Fiber Optical Patch Cord
Application:
Data Center
Length:
Customised
Jacket Material:
PVC/OFNP/OFNR/LSZH
Fiber Type:
Single Mode / Multimode
Packaging Details:
Paper box
Supply Ability:
100000Channel per month
Highlight:

Multimode SMA Patch Cord

,

High Power SMA Patch Cord

,

Singlemode SMA Patch Cord

Product Description

Product Overview



 High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord



  SMA Fiber optical patch cord

The SMA fiber optic patch cord, also known as FMMA connector, was one of the First fiber optic interconnect system that gained industry wide acceptance. The SMA fiber patch cable are widely used for industrial, military, medical and laser system.









Product Specfiications

Performance Level
Standard
Elite
Connector
Mode
Endface
IL(max) (dB)
RL(min) (dB)
IL(max) (dB)
RL(min) (dB)
MPO/MTP
MM OM5
8F/APC
≤0.50
≥20
≤0.35
≥20
12F/APC
≤0.50
≥20
≤0.35
≥20
24F/APC
≤0.50
≥20
≤0.35
≥20
8F/PC
≤0.50
≥20
≤0.35
≥20
12F/PC
≤0.50
≥20
≤0.35
≥20
24F/PC
≤0.50
≥20
≤0.35
≥20








Test Environment

High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 0    High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 1   High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 2  High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 3



    NO-dust workshop                High Temp. Ageing & High-Low               100% Testing Before              Optical Spectrum Analysis

                                                            Temperature cycling                            Shipment



Features and Applications



Features
Threaded nut connector
TIA / IEC compliant
Simple termination and assembly
Application
Medical / Surgical
Laser Systems
Spectrometers
Military







Product packaging

High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 4  High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 5  High Power SMA Laser Fiber Singlemode/Multimode SMA Patch Cord 6

           Finished Item              Inner Package                     Carton
