| Brand Name: | GEZHI or OEM |
| Model Number: | 8CH+13-CWDM-MD |
| MOQ: | 1pc |
| Price: | Negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union |
8 Channel CWDM multiplex and demultiplex with Grey 1310nm band ports
CWDM Mux Demux is based on planar Lightwave circuit technology and precision aligning process, can divide a single/dual optical input(s) into multiple optical outputs uniformly and is denoted 1xN or 2xN. PLC splitter is applied in FTTX deployments, PON networks, CATV links and optical signal distribution currently. DYSFO’ PLC splitter offers superior optical performance, high stability and high reliability, meet various application requirements in different environments.
Features | Applications |
|
|
Specification
| Parameter | CWDM Mux/Demux Unit | |
| Center Wavelength (nm) | ITU, ITU+1 | |
| Passband (nm) | ITU±7.5 | |
| Operating Wavelength (nm) | 1470~1610nm + Wide 1310nm | |
| Channel Space (nm) | 20 | |
| Fiber Type | SMF-28e or customer specified | |
| IL (dB) | <2.8dB | |
| Isolation(dB) | Adjacent Channel | 30 |
| Non-Adjacent Channel | 45 | |
| PDL (dB) | 0.2 | |
| PMD (ps) | 0.1 | |
| Return Loss (dB) | 45 | |
| Directivity (dB) | 50 | |
| Maximum Optical Power (mw) | 500 | |
| Operating Temperature (℃) | -20~+70 | |
| Storage Temperature (℃) | -40～85 | |
| Connector | LC/UPC | |
| Package (mm) | 19" 1U Rack Mount | |
Note: 1. Customization is available.
2. Specification maybe changed without notice.
8 Channel CWDM multiplex and demultiplex with Grey 1310nm band ports
Filter cascading
8CH+1310nm CWDM mux/demux 19" 1U Rack Mount
8 Channel Duplex CWDM Multiplex and demultiplex 1RU Solution
Advantages Of CWDM Mux Demux
1. Adopt high strength stainless steel, pass salt spray test
2. Ferrule core is less than 0.2um
3. Adopt 100% new raw material, ROHS compliance
4. Low Insertion loss
5. Low PDL Compact Design
6. Good channel-to-channel uniformity
7. Wide Operating Wavelength: from 1260nm to 1650nm
8. Wide Operating Temperature: from -40℃ to 85℃
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer Of CWDM Mux Demux. We can do OEM/ODM business.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
|
|
