| Brand Name: | GEZHI or OEM |
| Model Number: | 1x8-DWDM |
| MOQ: | 1pc |
| Price: | Negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union |
8CH Passive DWDM Mux ABS box module in Channel Add/Drop
GEZHI’ 8CH Passive DWDM Mux ABS Box module is based on the thin film coating technology with C45, C46, C47, C48, C49, C50, C51, C52 wavelength with a upgrade port for future development and Fibre Extender which is a low loss, high density passive optical module . The 8CH Passive DWDM Mux ABS Box module offers an high channel isolation WDM solution for Metro access applications and data centers . Its LC/UPC pigtailed with ABS box 100x80x10mm package. The 8CH Passive DWDM Mux ABS Box module is ideal for long-haul transport of fiber optic singals all over a dual fiber.
Features
Wide pass band
Low Insertion Loss
High channel
Epoxy-Free Optical Path
Telcordia GR-1221 CompliantHigh stability and reliability
Applications
Wavlength Routing
Dense WDM Systems
Metro Networks
Long Haul Networks
Channel Add/Drop
CATV Fiber Optic Links
Access / Enterprise Networks
Specification
| Parameter | Unit | 8CH Passive DWDM Mux | |
| Channel Number | -- | 8CH | |
| Operation Wavelength | nm | C45~C52 + Express Port | |
| Channel Central Wavelength | nm | ITU-T Grid @DWDM | |
| Channel Passband | nm | 0.8 (100Ghz) | |
| Insertion Loss @PB | dB | <2.8 | |
| Isolation @Adjacent Channel | dB | >30 | |
| Isolation @Non-adjacent Channel | dB | >40 | |
| Isolation @Reflect Channel | dB | >15 | |
| Passband Ripple | dB | <0.5 | |
| Polarization Dependent Loss | dB | <0.15 | |
| Polarization Mode Dispersion | ps | <0.1 | |
| Directivity & Return Loss | dB | Directivity: >50 Return Loss:>45 | |
| Power Handling | mW | <500 | |
| Connector | -- | LC/UPC | |
| Fiber Type | -- | SMF-28e or Customized | |
| Operating Temperature | ℃ | -20 ~ +70 | |
| Storage Temperature | ℃ | -40 ~ +85 | |
| Package Dimension | mm | ABS box 100x80x10mm | |
GEZHI's 8CH Passive DWDM Mux ABS Box module with Upgrade port C45~C52 wavelength offers high-capacity terminal DWDM solutions for network expansion. This 8CH Passive DWDM Mux ABS Box module is used for long-haul transmission where wavelengths are packed tightly together over the C-band, up to 48 wavelengths in 100GHz grid (0.8nm). The 8CH Passive DWDM Mux ABS Box module is protocol transparent and suited for applications including 10/1G Ethernet, SDH/SONET, CATV, 16/8/4/2/1G Fibre Channel, FTTx, etc.
8CH Passive DWDM Mux cascading
8CH Passive DWDM Mux
Single Fiber DWDM
ABS Box Package
|
|
