| Brand Name: | Gezhi or OEM |
| Model Number: | Gezhi-1x32 PLC |
| MOQ: | 1 pieces |
| Price: | Nigotiate |
| Delivery Time: | 7 Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
1x32 plc splitter Product description
PLC Splitter SC/UPC 1*32 Mini Type fiber optic plc splitter 1x32 plc splitter
PLC Splitter SC/UPC 1*32 Mini Type is 1*32 Sc/Upc Mini Type Optical Fiber Splitter with Low Insertion Loss Fiber Optical Splitter.
A planar optical wave circuit (PLC) splitter is an optical power management device manufactured using quartz optical waveguide technology. It has small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity and is widely used in PON networks to realize optical signal power distribution. We offer a full range of 1×N distributors, tailored to specific applications. All products meet the requirements of GR-1209-CORE-2001 and GR-1221-CORE-1999. The product features Low insertion loss, high isolation, low polarization-dependent loss , compact design, good channel-to-channel uniformity, wide operating wavelength range, high reliability and stability.
PLC Splitter SC/UPC 1*32 Mini Type Specifications
| Mini type 1*N PLC Splitter Datasheet | ||||||||
| Operating wavelength (nm) | 1260nm-1650nm | |||||||
| Fiber type | G657A1 or customer specified | |||||||
| Port configuration | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | 1×128 | |
| Insertion loss (dB) (P/S grade) | max | 3.8/4.0 | 7.1/7.3 | 10.2/10.5 | 13.5/13.7 | 16.5/16.9 | 20.5/21 | 23.8/24.2 |
| Loss uniformity (dB) | max | 0.6 | 0.6 | 0.8 | 1.2 | 1.5 | 2 | 2.5 |
| Polarization Dependent Loss (dB) | max | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 | 0.5 |
| Return Loss (dB) | min | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| Directivity (dB) | min | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| Wavelength Dependent Loss (dB) | max | 0.5 | 0.5 | 0.5 | 0.8 | 0.8 | 1 | 1.2 |
| Temperature stability(-40~85 °C)(dB) | max | 0.5 | 0.5 | 0.5 | 0.8 | 0.8 | 1 | 1.2 |
| Dimension (mm) (L×W×H) | 60×7×4 | 60×7×4 | 60×7×4 | 60×12×4 | 80×20×6 | 100×40×6 | N/A | |
FAQ
1. who are we?
We are based in Guangdong, China, start from 2014,sell to South America(25.00%),Eastern Asia(20.00%),North America(15.00%),Eastern Europe(10.00%),Western Europe(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
DWDM,CWDM,Filter WDM,AAWG DWDM,Mechanical Optical Switch
4. why should you buy from us not from other suppliers?
Gezhi Photonics is a factory which mainly produce Optical switches, DWDM, FWDM, CEx Module, CWDM, PatchCord, Optical Transceiver etc. We are focus on the quality and comply with ISO:9001, Rohs, CE, Reach, GR-1209-CORE and GR-1221-CORE standard
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,D/P D/A,PayPal,Cash;
Language Spoken:null
|
|
