| Brand Name: | GEZHI or OEM |
| Model Number: | PLC Splitter Cassette |
| MOQ: | 1 pieces |
| Price: | USD >= 1 pieces 5.6 |
| Delivery Time: | 7 Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Product description
1*64 PLC Splitter 130*101*206mm Cassette Type Plastic Insertion Module
The PLC Splitters is branching devices that is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal. PLC Splitter (Planar lightwave circuit splitter) is a type of optical power management device that is fabricated using silica optical waveguide technology. They are designed for FTTx Passive Optical Networks, CWDM, DWDM and optical cable TV System. PLC Splitter is responsible to distribute optical signals from Central Office (CO) to multiple premise locations.We provides whole series of 1*N and 2*N splitter products that are tailored for specific applications.
Feature
1. Loss is not sensitive to the wavelength of light, and can meet the transmission needs of different wavelengths.
2. The light is evenly distributed, and the signal can be evenly distributed to users.
3. The structure is compact and the volume is small, it can be directly installed in the existing various transfer boxes without leaving a large installation space.
4. There are many shunt channels for a single device, which can reach more than 32 channels.
5. Wide operating wavelength
Specification
| Port Configuration | 1×64 | |
| Operating Wavelength (nm) | 1260~1650 | |
| Insertion Loss (dB) | Typ. | 20.0 |
| Max. | 21.5 | |
| Loss Uniformity (dB) | Typ. | 1.5 |
| Max. | 2.5 | |
| Return Loss (dB) | 55 | |
| PDL (dB) | Typ. | 0.2 |
| Max. | 0.4 | |
| Directivity (dB) | 55 | |
| Fiber Type | SM G.657A1 | |
| Wavelength Dependent Loss (dB) | Typ. | 0.3 |
| Max. | 0.5 | |
| Temperature Stability (-40~+85°C) (dB) | Typ. | 0.4 |
| Max. | 0.5 | |
| Operating Temperature (°C) | -40~+85°C | |
| Storage Temperature (°C) | -40~+85°C | |
|
|
| Brand Name: | GEZHI or OEM |
| Model Number: | PLC Splitter Cassette |
| MOQ: | 1 pieces |
| Price: | USD >= 1 pieces 5.6 |
| Packaging Details: | inner box,Carton |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Product description
1*64 PLC Splitter 130*101*206mm Cassette Type Plastic Insertion Module
The PLC Splitters is branching devices that is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal. PLC Splitter (Planar lightwave circuit splitter) is a type of optical power management device that is fabricated using silica optical waveguide technology. They are designed for FTTx Passive Optical Networks, CWDM, DWDM and optical cable TV System. PLC Splitter is responsible to distribute optical signals from Central Office (CO) to multiple premise locations.We provides whole series of 1*N and 2*N splitter products that are tailored for specific applications.
Feature
1. Loss is not sensitive to the wavelength of light, and can meet the transmission needs of different wavelengths.
2. The light is evenly distributed, and the signal can be evenly distributed to users.
3. The structure is compact and the volume is small, it can be directly installed in the existing various transfer boxes without leaving a large installation space.
4. There are many shunt channels for a single device, which can reach more than 32 channels.
5. Wide operating wavelength
Specification
| Port Configuration | 1×64 | |
| Operating Wavelength (nm) | 1260~1650 | |
| Insertion Loss (dB) | Typ. | 20.0 |
| Max. | 21.5 | |
| Loss Uniformity (dB) | Typ. | 1.5 |
| Max. | 2.5 | |
| Return Loss (dB) | 55 | |
| PDL (dB) | Typ. | 0.2 |
| Max. | 0.4 | |
| Directivity (dB) | 55 | |
| Fiber Type | SM G.657A1 | |
| Wavelength Dependent Loss (dB) | Typ. | 0.3 |
| Max. | 0.5 | |
| Temperature Stability (-40~+85°C) (dB) | Typ. | 0.4 |
| Max. | 0.5 | |
| Operating Temperature (°C) | -40~+85°C | |
| Storage Temperature (°C) | -40~+85°C | |
