| Brand Name: | GEZHI or OEM |
| Model Number: | 1U 19" Rack Mount 1x128 PLC Splitter |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
1U 19" Rack Mount 1x128 Fiber Optic PLC Splitter Fiber Coupler
1x128 PLC Splitter - Introduction:
PLC (Planar Lightwave Circuit) splitters are Single Mode Splitters with an even split ratio from one input fiber to multiple output fibers. It is based on planar lightwave circuit technology and provides a low cost light distribution solution with small form factor and high reliability. TAKFLY provides a various of 1×N and 2×N PLC splitters, including 1×2 to 1×128 and 2×2 to 2×128 1U Rack Mount type fiber PLC splitters. They are all with superior optical performance, high stability and high reliability to meet various application requirements.
1x128 Fiber PLC Splitter - Feature:
1. Low Insertion Loss
2. Low Polarization Dependent Loss
3. Wide Operation Wavelength
4. Wide Operation Temperature
5. High Stability and Reliability
1x128 PLC Splitter - Applications:
1. Access Network
2. Telecom/CATV
3. Active device termination
4. Local Area Networks (LANS)
5. Metro
6. Test equipment
7. Data processing network
8. Wide Area Networks (WANS)
9. FTTX
1x128 Fiber PLC Splitter- Specification:
| Item | Parameter | |||||
| Operating Wavelength(nm) | 1260 ~ 1650 | |||||
| Type(1*N) | 1*2 | 1*4 | 1*8 | 1*16 | 1*32 | 1*64 |
| Insertion Loss(dB) | 3.9 | 7.2 | 10.3 | 13.5 | 16.8 | 20.3 |
| Max.Uniformity(dB) | 0.8 | 0.8 | 0.8 | 1.0 | 1.5 | 2.0 |
| Min.Return Loss(dB) | 55 | |||||
| Max.PDL(dB) | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 |
| Type(2*N) | 2*2 | 2*4 | 2*8 | 2*16 | 2*32 | 2*64 |
| Max.Insertion Loss(dB) | 4.2 | 7.5 | 10.6 | 13.9 | 17.2 | 20.8 |
| Max.Uniformity(dB) | 0.8 | 1.0 | 1.2 | 1.5 | 1.8 | 2.0 |
| Min.Return Loss(dB) | 55 | |||||
| Max.PDL(dB) | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 |
| Fiber Type | ITU-T G657A1 , G657A2 and G.652D | |||||
| Max.Temperature Stability(dB) | 0.5( Typical 0.3 ) | |||||
| Operating Temperature(℃) | -40 ~ +85 | |||||
| Storage Temperature(℃) | -40 ~ +85 | |||||
All measurement are made at room temperature, and connectors not included
1x128 Fiber PLC Splitter - Picture:
|
|
