| Brand Name: | GEZHI or OEM |
| Model Number: | 1x8 Cassette Optical splitter |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON
Description:
We offer several types of high-quality splitters. These products are designed for long-term reliability, superior performance, and a wide range of uses in fiber optics including optical transmission, long haul, subscriber loop, and fiber to the home, telecommunications, CATV, test equipment, optical fiber sensors, data communications and wide-area network.
Our optical splitters are designed for consistent performance, low optical loss, low polarization sensitivity, superior environmental and mechanical characteristics, and fast installation. They also enable more effective monitoring and management of fiber optical networks.
Feature:
Low PDL Compact Design
Ferrule core is less than 0.5um
Low Insertion loss
Wide Operating Wavelength: from 1260nm to 1650nm
Wide Operating Temperature: from -40℃ to 85℃
Application:
Access Network,EPON,GPON or WDM-PON
CATV system
Optical communication systems
Testing instruments
FTTH, FTTB
Performance:
Table1. 1XN PLC splitter(with connector)
| Parameters | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 |
| Operating Wavelength (nm) | 1260～1650 | |||||
| Insertion Loss (dB) | ≤4.3 | ≤7.5 | ≤11.0 | ≤14.0 | ≤17.0 | ≤21.0 |
| Loss Uniformity (dB) | ≤0.6 | ≤0.6 | ≤0.8 | ≤1.2 | ≤1.5 | ≤1.8 |
| PDL (dB) | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 |
| Return loss(dB) | UPC≥50dB；APC≥55dB | |||||
| Directivity (dB) | ≥55 | |||||
| Pigtail Length (m) | 1m or customer specified | |||||
| Fiber Type | G657A or customer specified | |||||
| Operation temperature(℃) | -40~85 | |||||
|
Note: All measurements were done at room temperature. Above parameters all testing at 1310nm,1550nm wavelength, if it test at 1260~1300nm,1600～1650nm,then insertion loss would be add 0.3dB based on above parameters. |
||||||
Table2. 2XN PLC splitter(with connector)
| Parameters | 2x2 | 2x4 | 2x8 | 2x16 | 2x32 | 2x64 |
| Operating Wavelength (nm) | 1260～1650 | |||||
| Insertion Loss (dB) | ≤4.5 | ≤8.0 | ≤11.7 | ≤14.7 | ≤17.9 | ≤21.2 |
| Loss Uniformity (dB) | ≤0.8 | ≤1.0 | ≤1.0 | ≤1.5 | ≤2.0 | ≤2.5 |
| PDL (dB) | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 |
| Return loss(dB) | UPC≥50dB；APC≥55dB | |||||
| Directivity (dB) | ≥55 | |||||
| Pigtail Length (m) | 1m or customer specified | |||||
| Fiber Type | G657A or customer specified | |||||
| Operation temperature(℃) | -40~85 | |||||
|
Note: All measurements were done at room temperature. Above parameters all testing at 1310nm,1550nm wavelength, if it test at 1260~1300nm,1600～1650nm,then insertion loss would be add 0.3dB based on above parameters. |
||||||
|
|
| Brand Name: | GEZHI or OEM |
| Model Number: | 1x8 Cassette Optical splitter |
| MOQ: | 1pc |
| Price: | Negotiable |
| Packaging Details: | Paper box |
| Payment Terms: | T/T, Western Union |
ABS Material Fiber Optic PLC Splitter 1X8 SCUPC Cassette Type Grey For WDM - PON
