Created with Pixso. LGX Cassette FTTH Filter WDM 1550nm Wdm Fiber Optic Multiplexer

LGX Cassette FTTH Filter WDM 1550nm Wdm Fiber Optic Multiplexer

Brand Name: GEZHI or OEM
Model Number: Pull cone splitter Optical Circulator
MOQ: 1pc
Price: Negotiable
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Return Loss:
≥45dB
Wavelength Bandwidth:
1310±30 Or 1550±30 Or 1585±30
Power Handling:
SMF-28e Or Customized
Opterating Temperature:
-10~+75
Use:
FTTH
Certification:
RoHS
Optical Connector::
C/APC&FC/APC&SC/PC
Outer Jacket:
LSZH,OFNP ,OFNR
Warranty Time:
13 Months, One Year
Packaging Details:
2pcs in a foam with plastic Box
Supply Ability:
50000pcs per month
Highlight:

Low Insertion Loss Optical Circulator

,

High Isolation Optical Circulator

Product Description

Pull cone splitter Optical Circulator Price Low


LGX Cassette FTTH Filter WDM 1550nm Wdm Fiber Optic Multiplexer 0

Specification

Parameters Unit FWDM Device
Operating Wavelength
T: transmission wavelength
R: reflection wavelength
1310±50,1490±10, 1550±10
1610±10, 1625±25, 1650±20
nm 1 T1550 R1310/1490
2 T1490 R1310/1550
3 T1310 R1490/1550
4 T1550/1610 R1310/1490
5 T1550/1625 R1310/1490
6 T1625 R1310/1490/1550
7 T1650 R1310/1490/1550
Insertion Loss of GPON FTTH WDM dB Transmission: ≤ 0.6
Reflection: ≤ 0.4
Transmission Channel Isolation dB ≥ 30
Reflection Channel Isolation dB ≥ 17
PDL of WDM in Optical Fiber dB ≤ 0.1
Wavelength thermal stability nm/℃ ≤ 0.003
Insertion loss thermal stability dB/℃ ≤ 0.005
Return loss dB ≥ 45
Optical Power mW ≤ 500
Operating Temperature -10 ~ +70
Storage Temperature -40 ~ +85
Relative Humidity % 5 ~ 95
Dimension mm Φ5.5×34 Φ4.2×25 90×20×10
Note: 1. Customization is available.
2. Specified without connector, and add an additional 0.2dB loss per connector.



Our Certificates

 LGX Cassette FTTH Filter WDM 1550nm Wdm Fiber Optic Multiplexer 1

Packing & Shipping

Original Carton Package.

As customers' requirement.

LGX Cassette FTTH Filter WDM 1550nm Wdm Fiber Optic Multiplexer 2

AFQ

Payment:

For large orders, T/T ,For small orders, Paupal are accepte

Warranty:

All products have been tested before shipping out All products have 1 years warranty. ( After the quality guarantee period began to charge appropriate maintenance service fee.

Refund $ Replacement:

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items If the items you purchase from our store are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund. If the items are defective, please notify us within 3 days of delivery. Any items must be returned in their original condition to qualify for a refund or replacement. The buyer is responsible for all the shipping cost incurred.

Could I use our own logo, label and package?

Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
