100GHz 8Channel DWDM Mux Demux duplex fiber with Monitor and Grey 1310nm wideband port in 4slot 1U Rackmount

Name: 100GHz 8Channel DWDM Mux Demux duplex fiber with Monitor and Grey 1310nm wideband port in 4slot 1U Rackmount
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 4slot 1U Rackmount DWDM
Price: Negotiable USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	4slot 1U Rackmount DWDM
MOQ:	1pc
Price:	Negotiable
Payment Terms:	Western Union, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Type:

FTTx Solutions

Use:

WDM System

Channel Spacing:

100GHz

Center Wavelength:

ITU Grid

Fiber Connector:

LC/UPC, FC/APC, SC/APC Etc.

Application:

Data Center

Packaging Details:

Paper box

Supply Ability:

5000pcs per month

Highlight:

100GHz DWDM Mux Demux

1310nm DWDM Mux Demux

8Channel DWDM Mux Demux

Product Description

Product Overview of 19" 4slot 1U Rackmount DWDM

8CH DWDM Mux Demux Plug-in Module with Upgrade+Monitor in 4-slot 1U Rack-Mount This DWDM Module is a low loss, high density passive optical module which based on the thin film coating technology with C53 to C60 wavelengthwith a upgrade port for future development and Fibre Extender and a monitor port to monitor the equipment status .Its built a 8CH+Upgrade+Monitor DWDM Mux and 8CH+Upgrade+Monitor DWDM Demux in a LGX cassette, then insert 4cards LGX cassette in a 19" 1U Rackmount.

Features

ITU CWDM Grid

Low Insertion Loss

Monitor Port

4-slot 19" 1U Rackmount to save place

High Stability and Reliability

Applications

FTTX

Long-haul transport

CATV Systems

Data Center

WDM Network

Specification

Parameter	Unit	8+1CH DWDM Mux+Demux
Channel Number	--	8+1CH
Operation Wavelength	nm	C53~C60+Upgrade+1% Monitor Port
Channel Central Wavelength	nm	ITU-T Grid @DWDM
Channel Passband	nm	0.8 (100Ghz)
Insertion Loss @PB	dB	<2.8
Mux 1% monitoring	dB	<24.3
Demux 1% monitoring	dB	<21.5
Isolation @Adjacent Channel	dB	>30
Isolation @Non-adjacent Channel	dB	>34
Isolation @Reflect Channel	dB	>15
Passband Ripple	dB	<0.5
Polarization Dependent Loss	dB	<0.15
Polarization Mode Dispersion	ps	<0.1
Directivity & Return Loss	dB	Directivity: >50 Return Loss:>45
Power Handling	mW	<500
Connector	--	SC/UPC or customized
Fiber Type	--	SMF-28e or Customized
Operating Temperature	℃	-20 ~ +70
Storage Temperature	℃	-40 ~ +85
Package Dimension	mm	4slot 19" 1U Rackmount

8Channel DWDM Filter Cascading

8CH DWDM Mux Demux Plug-in Module with Upgrade+Monitor in 4-slot 1U Rack-Mount 0

8CH DWDM Mux Demux Module Dual Fiber

Picture details

FAQ

Q1:Can I have a sample order? What is your MOQ?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available.  Also Mixed samples are acceptable.

Q2: What's the Lead time?

A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.

Q3: What are the payment terms?

A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.

Q4: What is your warranty time

A4: 3 years' warranty.

Q5: Could I use our own logo, label and package?

A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
