| Brand Name: | GEZHI or OEM |
| Model Number: | GZ-AAWG |
| MOQ: | 1pc |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
Product Description
AAWG module is based on the silica on silicon technology and no electrical power is required. The product offers high stability and reliability, and has small package size.
The product is Telcordia GR-1221-CORE qualified, and RoHS
Features
Applications
Performance Specifications
| Parameter | Unit | Value | ||
| Pass Band Type | Flat-top | Gaussian | ||
| Channel Spacing | GHz | 100 | ||
| Channel Number | 48/40 | |||
| Wavelength Accuracy | nm | 士0.05 | ||
| 1dB Pass Band | nm | ≥0.38 | 0.2 | |
| 3dB Pass Band | nm | ≥0.58 | 0.5 | |
| Insertion loss | dB | ≤6.0 | 5.0 | |
| Ripple | dB | ≤0.5 | ||
| Uniformity | dB | ≤1.5 | ||
| Adjacent Crosstalk | dB | ≥23 | ||
| Non-adjacent Crosstalk | dB | ≥29 | ||
| Total Crosstalk | dB | ≥21 | ||
| Polarization Dependent Loss (PDL) | dB | ≤0.5 | ||
| PMD | ps | ≤0.5 | ||
| Chromatic Dispersion | ps/nm | ±20 | ||
| Return Loss | dB | ≥40 | ||
| Fiber | Input Port | mm | 0.9 | |
| Output Ribbon | -- | |||
| Fan Out | mm | 0.9 | ||
| Operation Temperature | °C | -5~+65 | ||
| Storage Temperature | °C | -40~+85 | ||
| Package | mm | 120X 70X11 | ||
Note:
1.Without connector loss
2.Design guarantee
Order details
Packaging & Shipping
1.Shipment
International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 2-7 days.
2.Our Services
OEM and ODM
OEM/ODM order is available.
Guarantee
We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials. All the optical transceivers have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.
|
|
